TS-WB950V

For 13-20 m ton carrier

Okada’s wide product range of TS-WB concrete crushers give you a concrete solution for your carrier. Unlike some hydraulic breakers, TS-WB crushers do not emit noise or vibration and are environmentally friendly and safe.

DOWNLOAD BROCHUREDealer Logincontact sales
OPERATING WEIGHTLBS
KG
OIL FLOWGPM
LPM
OPERATING PRESSUREPSI
BAR
OVERALL LENGTHINCHES
MM
OVERALL WIDTHINCHES
MM
MAX JAW OPENINGINCHES
MM
CRUSHING FORCE AT TIPUS Tons
kN
CARRIER WEIGHT RANGE1000 LBS.
M TON
TS-WB950V
OPERATING WEIGHTLBS3740
KG1690
OIL FLOWGPM26-53
LPM100-200
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES90
MM2280
OVERALL WIDTHINCHES55
MM1405
MAX JAW OPENINGINCHES37
MM950
CRUSHING FORCE AT TIPUS Tons68
kN605
CARRIER WEIGHT RANGE1000 LBS.28-44
M TON13-20
TS-WD720V
OPERATING WEIGHTLBS1690
KG920
OIL FLOWGPM13-26
LPM50-100
OPERATING PRESSUREPSI4060
BAR280
OVERALL LENGTHINCHES73
MM1850
OVERALL WIDTHINCHES44
MM1105
MAX JAW OPENINGINCHES24
MM620
CRUSHING FORCE AT TIPUS Tons40
kN355
CARRIER WEIGHT RANGE1000 LBS.13-20
M TON6-9
TS-WB1100V
OPERATING WEIGHTLBS5600
KG2540
OIL FLOWGPM44-116
LPM167-439
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES104
MM2635
OVERALL WIDTHINCHES64
MM1625
MAX JAW OPENINGINCHES43
MM1100
CRUSHING FORCE AT TIPUS Tons106
kN940
CARRIER WEIGHT RANGE1000 LBS.40-55
M TON18-25
TS-WB1400V
OPERATING WEIGHTLBS9460
KG4290
OIL FLOWGPM66-132
LPM250-500
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES117
MM2970
OVERALL WIDTHINCHES79
MM1995
MAX JAW OPENINGINCHES55
MM1400
CRUSHING FORCE AT TIPUS Tons124
kN1100
CARRIER WEIGHT RANGE1000 LBS.66-88
M TON30-40
TS-WD1700V
OPERATING WEIGHTLBS10,940
KG4960
OIL FLOWGPM79-159
LPM300-600
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES124
MM3160
OVERALL WIDTHINCHES90
MM2275
MAX JAW OPENINGINCHES63
MM1600
CRUSHING FORCE AT TIPUS Tons148
kN1320
CARRIER WEIGHT RANGE1000 LBS.88-104
M TON40-48
TS-WB1900V
OPERATING WEIGHTLBS16,340
KG7410
OIL FLOWGPM92-198
LPM350-700
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES140
MM3560
OVERALL WIDTHINCHES102
MM2600
MAX JAW OPENINGINCHES75
MM1900
CRUSHING FORCE AT TIPUS Tons225
kN2000
CARRIER WEIGHT RANGE1000 LBS.132-220
M TON60-100
TS-WD2200V
OPERATING WEIGHTLBS21609
KG9800
OIL FLOWGPM92-198
LPM350-700
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES146
MM3705
OVERALL WIDTHINCHES122
MM3090
MAX JAW OPENINGINCHES87
MM2200
CRUSHING FORCE AT TIPUS Tons236
kN2100
CARRIER WEIGHT RANGE1000 LBS.154-220
M TON70-100
TS-WB2400V
OPERATING WEIGHTLBS26,460
KG12,000
OIL FLOWGPM92-198
LPM350-700
OPERATING PRESSUREPSI4350
BAR300
OVERALL LENGTHINCHES159
MM4050
OVERALL WIDTHINCHES124
MM3160
MAX JAW OPENINGINCHES94
MM2400
CRUSHING FORCE AT TIPUS Tons242
kN2150
CARRIER WEIGHT RANGE1000 LBS.330-
M TON150

360° Rotation Mechanism

TS-WB crushers are equipped with the ability to rotate 360°.

Twin High-Output Cylinders

Create tremendous crushing force.

Speed Valve

The unique Okada speed valve utilizes return oil from the hydraulic cylinders to greatly increase the cycle speed of the crusher and is standard on TS-WB crushers.

Wide Jaw Opening

With the widest jaw opening in its class, the TS-WB lets you tackle the most massive demolition jobs, processing large concrete beams and sections quickly and efficiently.
Wedge Arm

Wedge shaped crushing arms efficiently and powerfully penetrate and crush reinforced concrete.

Rebar Cutting Blade

Troublesome rebar can be processed as part of the crushing process.
